* Processor: NXP i.MX8M Mini. Quad-core ARM Cortex-A53 @ 1.8GHz + Cortex-M4 @ 400MHz
* RAM: 2GB
* Storage: 8GB
* Interfaces: 4x UART, 2x USB Host, 1x USB OTG, Gigabit Ethernet, MIPI CSI, MIPI DSI, Audio I/O, PCIe, MMC/SD, JTAG, CAN, RS485, Speaker, I2C, SPI, etc.
* Operating system: Linux 4.14.98 + Qt 5.0
* Dimensions: 118.6 x 102.3 mm
* Expansion Module: 4G model, WiFi, 10.1-inch LCD
The EM-IMX8M-MINI is a linux based single board computer (SBC) incorporates PICO-IMX8M-MINI SODIMM module which is based on NXP’s energy efficient i.MX8M Mini ARM Cortex A53 processor.
This i.MX8M Mini SBC is tailor made for a wide range of multimedia applications, featuring 2GB LPDDR4, 8GB eMMC, 2x USB 2.0, powerful network connectivity options including 4G, WiFi and Bluetooth. Robust multimedia features including 1080P60 video HEVC/H265/H264/VP9 decode with HDR, 2D/3D graphics acceleration, 16 audio channels (32bits), MIPI-DSI, and 1080p encoder and decoder.
Together with MIPI CSI camera inputs, MIPI DSI display outputs, flexible audio interfaces and comprehensive communication features, EM-IMX8M-MINI is ideal for Advanced graphics, machine vision, and other multimedia applications.
| Specifications | |
|---|---|
| SoC | NXP i.MX 8M Mini, 4x ARM Cortex-A53 @ 1.8GHz 1 MB L2 cache ARM Cortex-M4F @ 400MHz |
| GPU | GCNanoUltra for 3D acceleration (1x shader, OpenGL® ES 2.0) GC320 for 2D acceleration |
| Memory | 2GB LPDDR4 |
| Storage | 8GB eMMC flash |
| Power Management | ROHM BD71847 |
| Power Input | DC 5V/3A |
| USB | 1x USB 2.0 OTG, micro-USB connector 2x USB 2.0 Host, type-A connector |
| UART | 1x RS232(DB9), 3x UARTs(4-pin connector) |
| Ethernet | 10/100/1000 Mbps Ethernet RJ45 port via Realtek RTL8211E controller |
| Audio | WM8960 audio codec. 3.5mm audio jack, 2x 2-pin header for Speaker |
| Expand Audio interface | 8bit RX and 8bit TX SAI interface, 40-pin header (J5) |
| SD | Micro SD socket, SD3.01 |
| Display | MIPI-DSI, 4 data lanes, up to 1920 x 1080 @60Hz, 26-pin header (CON2) |
| RTC | Real time clock, powered by external battery |
| JTAG | JTAG debug interface, 10-pin header |
| CAN | 2-Pin connector (P4) |
| RS485 | Compatible 9-bit data format, 3-pin connector (P3) |
| Buttons | Reset (SW2), Power (SW3), Boot Mode (SW4) |
| Expand interface | 2x I2C, 1x SPI, 6x GPIO. 26-pin header (J11) |
| PCIe | PCIE2.1, for SSD or 4G module |
| Camera | MIPI-CSI, 4 data lanes, 26-pin header (CON1) |
| WiFi&Bluetooth | 802.11b/g/n WiFi, Bluetooth 4.0. AP6236 module |
| SIM | Nano SIM |
| Dimensions | Baseboard - 118.6 x 102.3 mm; Core board – 67.6 x 34.3 mm |
Block Diagram
PCB Dimension
| OS | Item | Feature | Description |
|---|---|---|---|
| Linux4.14.98 | Bootloader | Boot | u-boot 2018.03 |
| Boot mode | Boot from eMMC | ||
| Download | Download via USB OTG | ||
| Kernel | Version | Linux 4.14.98 | |
| File system format | Support ext2, ext3, ext4, fat, jeffs2, UBIFS, nfs, etc. Boardcon only provides ext4, R/W file system. | ||
| LED | Support | ||
| Serial | Support | ||
| RTC | Support | ||
| Ethernet | 10/100/1000 Mbps Ethernet | ||
| CAN | Support | ||
| RS485 | Support | ||
| WIFI | Support | ||
| USB host | Support | ||
| USB OTG | Support | ||
| LCD | Support | ||
| TOUCH | Support Touchscreen | ||
| eMMC | Support | ||
| MMC/SD | MMC mode | ||
| GPIO | Support | ||
| Audio I/O | Support | ||
| Embedded GUI | Qt/Embedded | qt 5.0 | |
| File system | TCP/IP | TCP/IP protocol | |
| Network ping | Check the network | ||
| Ifconfig, route | For network configuration and related service application | ||
| Basic tool | linux common cammands | cat, chmod, echo, free, init, kill, ls, mkdir, mount, ps, reboot, rm, yes, insmod, lsmod, rmmod, dd, df, aplay | |
| Tools | DNW, CRT, uuu.rar |
| Datasheet |
|
|
|
|
|
|
|
|
| Reference Manual |
|
|
|
|
|
|
| Tools |
|
|
| Expansion Module | Module Detail | Linux |
|---|---|---|
 4G |
EM05-E M.2 module | √ |
| WiFi&Bluetooth |
AP6236 Module. 2.4G WiFi + Bluetooth 4.0 | √ |
| MIPI LCD |
10.1-inch Capacitive Touch Screen，1280 x 800 | √ |
