Camera does not work properly on board with more than 4GB of memory. After the memory is upgraded from 4GB to 8GB, open the camera APP, the terminal will output:

[  100.488782] rga_mm: RGA_MMU unsupported Memory larger than 4G!
[  100.488814] rga_mm: scheduler core[4] unsupported mm_flag[0x0]!
[  100.488821] rga_mm: rga_mm_map_buffer map dma_buf error!
[  100.488826] rga_mm: job buffer map failed!
[  100.488831] rga_mm: dst channel map job buffer failed!
[  100.488834] rga_mm: failed to map buffer
[  100.488842] rga_job: rga_job_commit: failed to map job info
[  100.488896] rga_job: request[1] task[0] job_commit failed.
[  100.488909] rga_job: rga request commit failed!
[  100.488915] rga: request[1] submit failed!

Solution: Modify the source code according to the file ddr_than-4G.patch and compile it again.

upgrade_tool is a firmware upgrade tool for Linux. Flash image requires superuser privileges.
1. Download and execute upgrade_tool first.
2. Put the firmware files and upgrade_tool in the same directory.
3. Connect the USB OTG port from the board to your PC, press the recovery button from your board, and connect the power, wait a few seconds and release the button.
4. Use the commands to flash image.
Basic Commands

  //List devices
  upgrade_tool ld

  //Download boot
  upgrade_tool db rkxxloader.bin

  //Flash the partition table
  upgrade_tool di -p parameter.txt

  //Flash single partition image
  upgrade_tool di -k kernel.img

  //Falsh multiple partition images
  upgrade_tool di -u uboot.img -b boot.img

  //Flash the partition image with no defined abbreviation, you need to specify the partition name.
  //Take the vendor partition as an example
  upgrade_tool di -vendor vendor.img

  //When ab partition are used, it also needs to be handled in undefined cases.
  //Take boot_a and boot_b as example
  upgrade_tool di -boot_a boot.img -boot_b boot.img

  //Flash loader and reset
  upgrade_tool ul rkxxloader.bin

  //Upgrade firmware and reset
  upgrade_tool uf update.img

  //Erase device
  upgrade_tool ef rkxxloader.bin
