A vehicle tracking device is an electronic device that is usually installed somewhere around the dashboard in business vehicles. With today’s advanced capabilities in cellular and satellite communication, you can use GPS tracking devices for trucks, vans, vehicles, barges and equipment to better manage your mobile resources, no matter where they are located.
Boardcon Embedded Design offers vehicle tracking solutions customized specifically to your business needs. It is ideal for the companies that have specific reporting requirements and the resource to manage the software.
Boardcon vehicle tracking device is powered by Freescale/NXP i.MX6 UltraLite applications processor with 512MB DDL3 RAM and 4GB eMMC flash by default.
The device is comprised of a baseboard and a CPU board. Boardcon provides support for Linux for the board. A wide range of accessories and modules are also offered with the board including serial, USB OTG&Host, GPRS, GPS, WiFi, etc…

 PCB Dimension

If you order the development board or any question, please feel free to contact us at market@armdesigner.com

How to use SSH in Vehicle Tracking Device linux system?
A. The board default supports SSH. About details, please refer to the document:
ssh.pdf

Whether the Vehicle Tracking Device support USB OTG interface download?
A. Yes.

How to use GPIO on the  Vehicle Tracking Device?
A. User can use the follow command to view the gpio base:
# cd /sys/class/gpio
# for i in gpiochip* ; do echo `cat $i/label`: `cat $i/base` ; done
Then execute follow command to use GPIO.
#OUT_IO_NUMBER=3
#echo ${OUT_IO_NUMBER} > /sys/class/gpio/export
#echo "out" > /sys/class/gpio/gpio${OUT_IO_NUMBER}/direction
or #echo "in" > /sys/class/gpio/gpio${OUT_IO_NUMBER}/direction
#echo 1 > /sys/class/gpio/gpio${OUT_IO_NUMBER}/value
or #echo 0 > /sys/class/gpio/gpio${OUT_IO_NUMBER}/value
