1. Overview
1.1 Summary
The SBC1126B is a compact single board computer powered by Rockchip RV1126B. It features a 1.6GHz quad-core Cortex-A53 CPU, a 3 TOPS NPU for AI acceleration, advanced ISP/AI-ISP for image processing, and dual MIPI CSI inputs. With H.265/H.264 multi-stream encoding, rich industrial interfaces (USB3.0, CAN, RS485), and support for Debian / Buildroot, it’s ideal for edge AI cameras, intelligent surveillance, robotics, and embedded vision systems.
1.2 Product Parameters
Specifications |
|
|---|---|
CPU |
Rockchip RV1126B. Quad-core Cortex-A53 @ 1.6GHz |
NPU |
3 TOPS |
Memory |
2GB/4GB LPDDR4 |
Storage |
8GB/16GB/32GB/64GB/128GB/256GB eMMC Micro SD card slot |
Power Supply |
12V/3A DC input jack 7.4V Li-Battery |
USB |
1x USB3.0 DRD (Dual-Role Device) 4x USB2.0 Host 2.0 |
Connectivity |
1x 10/100Mbps Ethernet RJ45 port 1x 10/100/1000Mbps Ethernet RJ45 port 2.4G WiFi (802.11b/g/n) with Bluetooth 4.2 |
Serial Port |
1x Serial port for debug, 3-pin connector 1x UART, 6-pin connector 2x RS485, 3-pin connector |
Display |
MIPI DSI, 26-pin header |
Audio |
1x Speaker, 2-pin connector 1x differential MIC |
Camera |
4x 2-lane MIPI CSI, 24-pin FPC connector |
Keys |
Recovery, Power, Reset |
Other features |
Supercap-powered RTC 2x CAN, 2-pin connector 6x ADC, 8-pin connector 1x SPI(SPI1_M2), 6-pin connector IR, 3-pin connector |
Dimensions |
Based board – 135 x 95mm; CPU module - 34 x 30mm |
